How to Configure Extended Protection in Exchange Server 2019/2016

Microsoft provides an official PowerShell script to manage Extended Protection across Exchange servers. Download this script from the official GitHub repository.

# Create scripts directory
New-Item -Path "C:\Scripts" -ItemType Directory -Force

# Download the official script (use browser or PowerShell)
Invoke-WebRequest -Uri "https://github.com/microsoft/CSS-Exchange/raw/main/Security/ExchangeExtendedProtectionManagement/ExchangeExtendedProtectionManagement.ps1" -OutFile "C:\Scripts\ExchangeExtendedProtectionManagement.ps1"

# Set execution policy if needed
Set-ExecutionPolicy -ExecutionPolicy RemoteSigned -Scope CurrentUser

Navigate to the scripts directory and verify the download:

cd C:\Scripts
Get-ChildItem ExchangeExtendedProtectionManagement.ps1 | Select-Object Name, Length, LastWriteTime

Before making changes, assess the current Extended Protection configuration across all Exchange servers and virtual directories.

# Open Exchange Management Shell as Administrator
# Run the status check command
.\ExchangeExtendedProtectionManagement.ps1 -ShowExtendedProtection

The script will display a comprehensive report showing:

• Server names and their Extended Protection status
• Virtual directories (OWA, ECP, EWS, ActiveSync, etc.)
• TokenChecking values: None, Accept, or Required
• ExtendedProtectionFlags: None or Proxy

Example output interpretation:

Server: EX01
  OWA: TokenChecking=None, Flags=None (VULNERABLE)
  ECP: TokenChecking=None, Flags=None (VULNERABLE)
  EWS: TokenChecking=Required, Flags=Proxy (PROTECTED)

Extended Protection requires specific minimum versions and consistent configuration across your Exchange environment.

# Check Exchange version and cumulative updates
Get-ExchangeServer | Select-Object Name, Edition, AdminDisplayVersion

# Verify TLS configuration consistency
Get-ExchangeServer | ForEach-Object {
    $server = $_.Name
    Write-Host "Checking TLS on $server"
    Invoke-Command -ComputerName $server -ScriptBlock {
        Get-ItemProperty -Path "HKLM:\SYSTEM\CurrentControlSet\Control\SecurityProviders\SCHANNEL\Protocols\TLS 1.2\Server" -Name "Enabled" -ErrorAction SilentlyContinue
    }
}

Check for Hybrid deployment considerations:

# Identify Hybrid Agent servers (if applicable)
Get-HybridConfiguration | Select-Object SendingTransportServers, ReceivingTransportServers

# Check for Modern Hybrid setup
Get-IntraOrganizationConnector | Select-Object Name, TargetAddressDomains

Requirements verification:

• Exchange 2019: CU14 or later (auto-enables EP)
• Exchange 2016: Minimum August 2022 Security Update
• Exchange 2013: Minimum August 2022 Security Update
• TLS versions: Must be identical across all servers

Use the Microsoft script to enable Extended Protection across all Exchange servers. The script handles prerequisites checking and applies consistent configuration.

For standard Exchange deployments:

# Enable Extended Protection on all servers
.\ExchangeExtendedProtectionManagement.ps1

# The script will:
# 1. Check prerequisites (CU/SU versions, TLS consistency)
# 2. Set ExtendedProtectionTokenChecking=Required
# 3. Set ExtendedProtectionFlags=Proxy on virtual directories
# 4. Apply changes to OWA, ECP, EWS, ActiveSync, PowerShell, Autodiscover, OAB, MAPI

For Hybrid deployments (exclude Front-End EWS):

# Modern Hybrid - exclude EWS Front-End to prevent authentication issues
.\ExchangeExtendedProtectionManagement.ps1 -ExchangeServerNames "EX01,EX02" -ExcludeVirtualDirectories "EWSFrontEnd"

For specific servers only:

# Target specific servers
.\ExchangeExtendedProtectionManagement.ps1 -ExchangeServerNames "EX01,EX02,EX03"

Monitor the script execution for any errors or warnings. The script provides detailed output showing each virtual directory being configured.

.\ExchangeExtendedProtectionManagement.ps1 -ShowExtendedProtection

For granular control or troubleshooting, configure Extended Protection manually using Exchange Management Shell cmdlets.

Configure Client Access Services:

# Set Extended Protection on Client Access Services
Get-ClientAccessService | Set-ClientAccessService -ExtendedProtectionTokenChecking Required

Configure individual virtual directories:

# Web Services (EWS)
Get-WebServicesVirtualDirectory | Set-WebServicesVirtualDirectory -ExtendedProtectionTokenChecking Required -ExtendedProtectionFlags Proxy

# Outlook Web App (OWA)
Get-OwaVirtualDirectory | Set-OwaVirtualDirectory -ExtendedProtectionTokenChecking Required -ExtendedProtectionFlags Proxy

# Exchange Control Panel (ECP)
Get-EcpVirtualDirectory | Set-EcpVirtualDirectory -ExtendedProtectionTokenChecking Required -ExtendedProtectionFlags Proxy

# ActiveSync
Get-ActiveSyncVirtualDirectory | Set-ActiveSyncVirtualDirectory -ExtendedProtectionTokenChecking Required -ExtendedProtectionFlags Proxy

# PowerShell
Get-PowerShellVirtualDirectory | Set-PowerShellVirtualDirectory -ExtendedProtectionTokenChecking Required -ExtendedProtectionFlags Proxy

# Autodiscover
Get-AutodiscoverVirtualDirectory | Set-AutodiscoverVirtualDirectory -ExtendedProtectionTokenChecking Required -ExtendedProtectionFlags Proxy

For advanced scenarios, configure directly via IIS web.config:

# Configure multiple virtual directories in bulk
$VirtualDirectories = @("Microsoft-Server-ActiveSync","OWA","ECP","EWS","OAB","PowerShell","Autodiscover","MAPI")
foreach ($VDir in $VirtualDirectories) {
    try {
        Set-WebConfigurationProperty -Filter "system.webServer/security/authentication/windowsAuthentication" -Name "extendedProtection.tokenChecking" -Value "Required" -PSPath "IIS:\" -Location "Default Web Site/$VDir"
        Set-WebConfigurationProperty -Filter "system.webServer/security/authentication/windowsAuthentication" -Name "extendedProtection.flags" -Value "Proxy" -PSPath "IIS:\" -Location "Default Web Site/$VDir"
        Write-Host "Configured Extended Protection for $VDir" -ForegroundColor Green
    }
    catch {
        Write-Warning "Failed to configure $VDir: $($_.Exception.Message)"
    }
}

# Verify OWA configuration
Get-OwaVirtualDirectory | Select-Object Server, Name, ExtendedProtectionTokenChecking, ExtendedProtectionFlags

# Verify EWS configuration
Get-WebServicesVirtualDirectory | Select-Object Server, Name, ExtendedProtectionTokenChecking, ExtendedProtectionFlags

Use IIS Manager for visual configuration and troubleshooting of Extended Protection settings on individual virtual directories.

Open IIS Manager and navigate to virtual directories:

# Open IIS Manager
inetmgr.exe

Manual configuration steps:

1. Navigate to Sites → Default Web Site (or Exchange Back End)
2. Select a virtual directory (e.g., OWA, ECP, EWS)
3. Double-click Authentication in the Features View
4. Select Windows Authentication → Advanced Settings
5. Set Extended Protection to "Required"
6. Set Extended Protection Flags to "Proxy" (if using load balancer) or "None" (direct connection)

Verify the configuration in web.config:

# Check web.config for Extended Protection settings
$webConfigPath = "C:\Program Files\Microsoft\Exchange Server\V15\FrontEnd\HttpProxy\owa\web.config"
[xml]$webConfig = Get-Content $webConfigPath
$windowsAuth = $webConfig.configuration.'system.webServer'.security.authentication.windowsAuthentication
Write-Host "Extended Protection Token Checking: $($windowsAuth.extendedProtection.tokenChecking)"
Write-Host "Extended Protection Flags: $($windowsAuth.extendedProtection.flags)"

For multiple virtual directories, use PowerShell to verify IIS settings:

# Check IIS configuration for all Exchange virtual directories
$VDirs = @("OWA", "ECP", "EWS", "Microsoft-Server-ActiveSync", "PowerShell", "Autodiscover")
foreach ($VDir in $VDirs) {
    try {
        $tokenChecking = Get-WebConfigurationProperty -Filter "system.webServer/security/authentication/windowsAuthentication" -Name "extendedProtection.tokenChecking" -PSPath "IIS:\" -Location "Default Web Site/$VDir"
        $flags = Get-WebConfigurationProperty -Filter "system.webServer/security/authentication/windowsAuthentication" -Name "extendedProtection.flags" -PSPath "IIS:\" -Location "Default Web Site/$VDir"
        Write-Host "$VDir - TokenChecking: $($tokenChecking.Value), Flags: $($flags.Value)" -ForegroundColor $(if($tokenChecking.Value -eq "Required"){"Green"}else{"Red"})
    }
    catch {
        Write-Warning "Could not check $VDir configuration"
    }
}

Comprehensive testing ensures Extended Protection is working correctly and not blocking legitimate authentication.

Create a comprehensive verification script:

# Comprehensive Extended Protection verification
$Report = @()
$VDirTypes = @(
    @{Cmdlet="Get-OwaVirtualDirectory"; Type="OWA"},
    @{Cmdlet="Get-EcpVirtualDirectory"; Type="ECP"},
    @{Cmdlet="Get-WebServicesVirtualDirectory"; Type="EWS"},
    @{Cmdlet="Get-ActiveSyncVirtualDirectory"; Type="ActiveSync"},
    @{Cmdlet="Get-PowerShellVirtualDirectory"; Type="PowerShell"},
    @{Cmdlet="Get-AutodiscoverVirtualDirectory"; Type="Autodiscover"}
)

foreach ($VDirType in $VDirTypes) {
    $VDirs = & $VDirType.Cmdlet
    foreach ($VDir in $VDirs) {
        $Report += [PSCustomObject]@{
            Server = $VDir.Server
            Type = $VDirType.Type
            Name = $VDir.Name
            TokenChecking = $VDir.ExtendedProtectionTokenChecking
            Flags = $VDir.ExtendedProtectionFlags
            Status = if($VDir.ExtendedProtectionTokenChecking -eq "Required"){"PROTECTED"}else{"VULNERABLE"}
        }
    }
}

$Report | Format-Table -AutoSize
$Report | Where-Object {$_.Status -eq "VULNERABLE"} | Format-Table -AutoSize

Test client connectivity after enabling Extended Protection:

# Test OWA connectivity
Test-OwaConnectivity -ClientAccessServer EX01 -MailboxCredential (Get-Credential)

# Test EWS connectivity
Test-WebServicesConnectivity -ClientAccessServer EX01 -MailboxCredential (Get-Credential)

# Test ActiveSync connectivity
Test-ActiveSyncConnectivity -ClientAccessServer EX01 -MailboxCredential (Get-Credential)

Monitor Exchange logs for authentication issues:

# Check recent authentication events
Get-WinEvent -LogName "Microsoft-Exchange-HttpProxy/HttpProxy" -MaxEvents 50 | Where-Object {$_.LevelDisplayName -eq "Error" -or $_.LevelDisplayName -eq "Warning"} | Select-Object TimeCreated, LevelDisplayName, Message

Test from external clients (if applicable):

• Outlook clients: Verify autodiscover and mailbox access
• Mobile devices: Test ActiveSync connectivity
• Web browsers: Access OWA from different networks
• Third-party applications: Test EWS-based integrations

If Extended Protection causes connectivity issues, you can rollback the configuration or troubleshoot specific problems.

Rollback using the official script:

# Rollback Extended Protection to previous state
.\ExchangeExtendedProtectionManagement.ps1 -Rollback

# The script will:
# 1. Restore previous ExtendedProtectionTokenChecking values
# 2. Reset ExtendedProtectionFlags to None
# 3. Restore IIS configuration from backup

Manual rollback via PowerShell:

# Disable Extended Protection on all virtual directories
Get-OwaVirtualDirectory | Set-OwaVirtualDirectory -ExtendedProtectionTokenChecking None -ExtendedProtectionFlags None
Get-EcpVirtualDirectory | Set-EcpVirtualDirectory -ExtendedProtectionTokenChecking None -ExtendedProtectionFlags None
Get-WebServicesVirtualDirectory | Set-WebServicesVirtualDirectory -ExtendedProtectionTokenChecking None -ExtendedProtectionFlags None
Get-ActiveSyncVirtualDirectory | Set-ActiveSyncVirtualDirectory -ExtendedProtectionTokenChecking None -ExtendedProtectionFlags None
Get-PowerShellVirtualDirectory | Set-PowerShellVirtualDirectory -ExtendedProtectionTokenChecking None -ExtendedProtectionFlags None
Get-AutodiscoverVirtualDirectory | Set-AutodiscoverVirtualDirectory -ExtendedProtectionTokenChecking None -ExtendedProtectionFlags None

Common troubleshooting scenarios:

# Check for TLS version mismatches
Get-ExchangeServer | ForEach-Object {
    $server = $_.Name
    Write-Host "Checking $server TLS configuration..."
    Invoke-Command -ComputerName $server -ScriptBlock {
        $tls12 = Get-ItemProperty -Path "HKLM:\SYSTEM\CurrentControlSet\Control\SecurityProviders\SCHANNEL\Protocols\TLS 1.2\Server" -ErrorAction SilentlyContinue
        $tls13 = Get-ItemProperty -Path "HKLM:\SYSTEM\CurrentControlSet\Control\SecurityProviders\SCHANNEL\Protocols\TLS 1.3\Server" -ErrorAction SilentlyContinue
        [PSCustomObject]@{
            Server = $env:COMPUTERNAME
            TLS12Enabled = $tls12.Enabled
            TLS13Enabled = $tls13.Enabled
        }
    }
}

# Check for certificate issues
Get-ExchangeCertificate | Where-Object {$_.Status -ne "Valid"} | Select-Object Thumbprint, Subject, Status, NotAfter

Hybrid-specific troubleshooting:

# For Hybrid deployments, ensure EWS Front-End is excluded
Get-WebServicesVirtualDirectory | Where-Object {$_.Name -like "*FrontEnd*"} | Select-Object Server, Name, ExtendedProtectionTokenChecking

# If Front-End EWS shows "Required", disable it:
Get-WebServicesVirtualDirectory | Where-Object {$_.Name -like "*FrontEnd*"} | Set-WebServicesVirtualDirectory -ExtendedProtectionTokenChecking None

Load balancer troubleshooting:

• SSL bridging: Ensure same certificate on all servers
• Proxy flags: Verify "Proxy" flags are set correctly
• Health checks: Update load balancer health check URLs if needed
